Foot Valve 150MM
Product Overview
Foot Valve 150mm is a bottom-mounted check valve designed to maintain pump priming by preventing reverse flow in suction pipelines. It is widely used in water intake and transfer systems.
Key Features
Integrated stainless steel strainer prevents large particles and debris from entering the pipeline and pump system.
EPDM-coated disc sealing structure improves sealing performance and reduces backflow risk during shutdown.
Ductile iron body construction provides high mechanical strength and long service life under working pressure conditions.
Stainless steel internal components improve corrosion resistance in water and sewage applications.
Low opening resistance design helps reduce suction loss and improve pump operating efficiency.
Flanged connection configuration supports compatibility with multiple international piping standards.
Technical Specifications
| Parameter | Specification |
| Product Type | Foot Valve |
| Nominal Size | DN150 (150mm / 6") |
| Available Size Range | DN50–DN300 (2"–12") |
| Pressure Rating | PN10 / PN16 / PN25 |
| Working Medium | Water / Sewage |
| Connection Type | Flanged |
| Flange Standard | ANSI / GB / BS |
| Color Options | Blue / Red |
| Working Temperature | Depends on sealing material and medium conditions |
Material Details
| Component | Material |
| Body | Ductile Iron QT450-10 |
| Strainer | Stainless Steel 304 |
| Stem | Stainless Steel 304 |
| Disc | Ductile Iron with EPDM Coating |
| Spring | Stainless Steel 304 |
| Bushing | Bronze |
| Seal | EPDM |
Application Scenarios
Pump suction pipeline systems
Groundwater extraction systems
Raw water intake systems
Water transfer and distribution pipelines
Irrigation pumping systems
Sewage pumping systems
Reservoir and tank suction installations
Municipal water supply pumping stations
Industrial process water circulation systems
Quality Assurance
Raw material inspection for chemical composition and mechanical property verification
Dimensional inspection according to drawing and flange standard requirements
Pressure testing including shell strength test and sealing test
Leakage inspection for valve seat sealing performance verification
Coating thickness inspection where coating is required
Surface and appearance inspection before packaging
Material traceability control during production process
ISO 9001 quality management system compliance
Optional EN 10204 3.1 material certificate
Optional third-party inspection support (SGS / BV / TUV)
Customization Options
| Item | Available Options |
| Logo Marking | Cast logo / Laser marking / Nameplate |
| Packaging | Plywood case / Carton / Customized export packaging |
| Flange Standard | ANSI / DIN / BS / JIS / GB |
| Material Upgrade | SS316 / Full Stainless Steel / Alternative sealing materials |
| Coating | Epoxy coating / Anti-corrosion coating |
| Color | Blue / Red / Customized colors |
| Pressure Class | PN10 / PN16 / PN25 |
| Seal Material | EPDM / NBR / Viton |
| Connection Type | Flanged / Customized connection |
